Apex 3

The Datamax-O-Neil Apex 3 offers a solution to the demand for an affordable, light weight and compact three-inch receipt printer without compromising on quality and reliability. The Apex 3 prints a receipt of up to 3.13" wide and has the key features and functions required to meet the expanding requirements associated with retail, hospitality, law enforcement, car rental and field service applications.


  • Product Type: Direct Thermal Printer
  • Brand Name: Datamax-O'Neil
  • Manufacturer: Datamax-O'Neil
  • Product Model: 78828S1-3
  • Product Name: 78828S1-3 Apex 3 Receipt Printer


Print Specification

6.1" L x 5.0" W x 2.3" H
156 mm L x 127 mm W x 58 mm H

18.5 oz (524 g)

2.83" (72 mm)

3.13" (80 mm)

4MB Flash / 1MB RAM

Print Technology

Direct Thermal
203 dots per inch (8 dots per mm)

2 inches per second (51 mm per second) on Apex 2 and 3

User Guides and Manuals

Name Date Size
Apex 3 Spec Sheet 24/01/2019 PDF 1.12 MB
